Specifications

Rated Power Output

100 W

Nominal Input Level (1 kHz)

CH1 (XLR type, MIC/LINE): -50-- -20 dBu
CH2 (LINE): -20 dBu
CH3 (LINE): -20 dBu
CH4 (MONITOR): -20 dBu
AUX IN (L, R, STEREO): -10 dBu

Nominal Output Level (1 kHz)

LINE OUT: +4 dBu
SUB OUT: +4 dBu

Speakers

30 cm (12 inches) Woofer x 1
Tweeter x 1

Controls

POWER switch

[CH1]
MIC/LINE knob

[CH2]
LINE knob

[CH3]
LINE knob

[CH4]
MONITOR knob

[EQUALIZER]
LOW knob
HIGH knob

MASTER knob

Indicator

Power

Connectors

CH1 jack: XLR type
CH1 (MIC/LINE) jack: 1/4-inch phone type
CH2 (LINE) jack: 1/4-inch phone type
CH3 (LINE) jack: 1/4-inch phone type
CH4 (MONITOR) jack: 1/4-inch phone type
AUX IN (L, R) jacks: RCA phono type
AUX IN (STEREO) jacks: Stereo miniature phone type
LINE OUT jack: 1/4-inch phone type
SUB OUT jack: 1/4-inch phone type
PHONES jack: 1/4-inch TRS phone type (mono signal output)

Power Consumption

70 W

Accessory

Owner's Manual

Option (sold separately)

Speaker stand: ST-A95

Size and Weight

Width

480 mm
18-15/16 inches

Depth

295 mm
11-5/8 inches

Height

435 mm
17-1/8 inches

Weight

15 kg
33 lbs 2 oz

* 0 dBu = 0.775 Vrms

*The specifications are subject to change without notice.
